Ceramic bearing 6200 6201 6202 6203 6204 6205 6206 6207

Short Description:

The ring and rolling body of ceramic bearing are made of all-ceramic materials, including zirconia (ZrO2), silicon nitride (Si3N4) and silicon carbide (Sic). The retainer is made of polytetrafluoroethylene, nylon 66, polyetherimide, zirconia, silicon nitride, stainless steel or special aviation aluminum, thus expanding the application surface of ceramic bearings.


Product Detail

Product Tags

Product name: Ceramic deep groove ball bearing

Material: Lead oxide meet the demand of strength and hardness,It is pure in color and adopt G5 high-precision ceramic ball with small bounce and high smoothness.

Chamfer: Clear and round ,fine workmanship in place

Tolerance: The tolerance of inner diameter,outer diameter and height is less than 0.3 wire(0.003mm) .

Purpose: In aerospace.navigation, petroleum, chemical industry, industry, machinery, power, subway, machine tools and other fields need high temperature corrosion under harsh environment.

As an important mechanical foundation, ceramic bearings take the lead in the world of new materials because of their excellent performance that metal bearings cannot match. In the past ten years, it has been increasingly widely used in various fields of national economy and people’s livelihood. Ceramic bearing has the characteristics of high temperature resistance, cold resistance, wear resistance, corrosion resistance, magnetoelectric insulation, oil-free self-lubrication, high speed and so on. Can be used in extremely harsh environment and special conditions, can be widely used in aviation, aerospace, navigation, petroleum, chemical industry, automotive, electronic equipment, metallurgy, electric power, textile, pump, medical equipment, scientific research and national defense and other fields, is a new material application of high-tech products.




  • Previous:
  • Next:

  • We have completely production line, and are always strictly controlling each process of production, from raw material making, turning to heat treatment, from grinding to assembly, from cleaning, oiling to packing etc. The operation of each process is very meticulously. In the process of production, through self-inspection, follow inspection, sampling inspection, full inspection, such as strict as quality inspection, it made all the performances reached the international standard. At the same time, the company set up advanced testing center, introduced the most advanced testing instrument: three coordinates, length measuring instrument, spectrometer, profiler, roundness meter, vibration meter, hardness meter, metallographic analyzer, bearing fatigue life testing machine and other measuring instruments etc. About the quality of the product to entire prosecution, the comprehensive performance of comprehensive inspection products, ensure JITO to reach the level of zero defect products!
