Ceramic Plastic bearings Nylon bearings Stainless steel bearings 6210

Short Description:

The ring and rolling body of ceramic bearing are made of all-ceramic materials, including zirconia (ZrO2), silicon nitride (Si3N4) and silicon carbide (Sic). The retainer is made of polytetrafluoroethylene, nylon 66, polyetherimide, zirconia, silicon nitride, stainless steel or special aviation aluminum, thus expanding the application surface of ceramic bearings.


Product Detail

Product Tags

Product name: Ceramic deep groove ball bearing

Material: Lead oxide meet the demand of strength and hardness,It is pure in color and adopt G5 high-precision ceramic ball with small bounce and high smoothness.

Chamfer: Clear and round ,fine workmanship in place

Tolerance: The tolerance of inner diameter,outer diameter and height is less than 0.3 wire(0.003mm) .

Purpose: In aerospace.navigation, petroleum, chemical industry, industry, machinery, power, subway, machine tools and other fields need high temperature corrosion under harsh environment.

As an important mechanical foundation, ceramic bearings take the lead in the world of new materials because of their excellent performance that metal bearings cannot match. In the past ten years, it has been increasingly widely used in various fields of national economy and people’s livelihood. Ceramic bearing has the characteristics of high temperature resistance, cold resistance, wear resistance, corrosion resistance, magnetoelectric insulation, oil-free self-lubrication, high speed and so on. Can be used in extremely harsh environment and special conditions, can be widely used in aviation, aerospace, navigation, petroleum, chemical industry, automotive, electronic equipment, metallurgy, electric power, textile, pump, medical equipment, scientific research and national defense and other fields, is a new material application of high-tech products.
